thumbnail
This part of DS 781 presents data for bathymetry for several seafloor maps of the Offshore of Point Conception Map Area, California. The vector data file is included in "BathymetryHS_OffshorePointConception.zip," which is accessible from https://doi.org/10.5066/F7QN64XQ. Shaded-relief bathymetry of the Offshore of Point Conception map area in southern California was generated largely from acoustic-bathymetry data collected by Fugro Pelagos Inc. Acoustic mapping was completed in 2008 using a combination of 400-kHz Reson 7125, 240-kHz Reson 8101, and 100-kHz Reson 8111 multibeam echosounders. Bathymetric-lidar data was collected in the nearshore area by the U.S. Army Corps of Engineers (USACE) Joint Lidar Bathymetry...
thumbnail
This part of DS 781 presents data for the Seafloor character map of the Offshore of Point Conception Map Area, California. The vector data file is included in "SeafloorCharacter_OffshorePointConception.zip," which is accessible from https://doi.org/10.5066/F7QN64XQ. This raster-format seafloor-character map shows four substrate classes in the Offshore of Point Conception map area, California. The substrate classes mapped in this area have been colored to indicate which of the following California Marine Life Protection Act depth zones and slope classes they belong: Depth Zone 2 (intertidal to 30 m), Depth Zone 3 (30 to 100 m), Depth Zone 4 (100 to 200 m), Depth Zone 5 (deeper than 200 m), Slope Class 1 (0 degrees...
thumbnail
This part of DS 781 presents data for the bathymetry map of Offshore Scott Creek, California. The raster data file is included in "Bathymetry_OffshoreScottCreek.zip", which is accessible from https://doi.org/10.5066/F7CJ8BJW. These data accompany the pamphlet and map sheets of Cochrane, G.R., Dartnell, P., Johnson, S.Y., Greene, H.G., Erdey, M.D., Dieter, B.E., Golden, N.E., Endris, C.A., Hartwell, S.R., Kvitek, R.G., Davenport, C.W., Watt, J.T., Krigsman, L.M., Ritchie, A.C., Sliter, R.W., Finlayson, D.P., and Maier, K.L. (G.R. Cochrane and S.A. Cochran, eds.), 2015, California State Waters Map Series--Offshore of Scott Creek, California: U.S. Geological Survey Open-File Report 2015-1191, pamphlet 40 p., 10 sheets,...
Categories: Data; Types: Downloadable, GeoTIFF, Map Service, Raster; Tags: Acoustic Reflectivity, CMHRP, Coastal and Marine Hazards and Resources Program, Continental/Island Shelf, Marine Nearshore Subtidal, All tags...
thumbnail
This part of DS 781 presents data for the faults for the geologic and geomorphic map of the Offshore of Scott Creek map area, California. The vector data file is included in "Faults_OffshoreScottCreek.zip," which is accessible from https://doi.org/10.5066/F7CJ8BJW. These data accompany the pamphlet and map sheets of Cochrane, G.R., Dartnell, P., Johnson, S.Y., Greene, H.G., Erdey, M.D., Dieter, B.E., Golden, N.E., Endris, C.A., Hartwell, S.R., Kvitek, R.G., Davenport, C.W., Watt, J.T., Krigsman, L.M., Ritchie, A.C., Sliter, R.W., Finlayson, D.P., and Maier, K.L. (G.R. Cochrane and S.A. Cochran, eds.), 2015, California State Waters Map Series--Offshore of Scott Creek, California: U.S. Geological Survey Open-File...
thumbnail
This portion of the USGS data release presents bathymetry data collected during surveys performed in the Columbia River littoral cell, Washington and Oregon in 2014 (USGS Field Activity Number 2014-631-FA). Bathymetry data were collected using four personal watercraft (PWCs) equipped with single-beam sonar systems and global navigation satellite system (GNSS) receivers. The sonar systems consisted of an Odom Echotrac CV-100 single-beam echosounder and 200 kHz transducer with a 9 degree beam angle. Raw acoustic backscatter returns were digitized by the echosounder with a vertical resolution of 1.25 cm. Depths from the echosounders were computed using sound velocity profiles measured using a YSI CastAway CTD during...
thumbnail
This portion of the USGS data release presents topography data collected during surveys performed on the Elwha River delta, Washington, in May 2011 (USGS Field Activity Number W-04-11-PS). Topography data were collected on foot with global navigation satellite system (GNSS) equipment mounted on backpacks operating in Real-Time Kinematic (RTK) mode. A total of 3 GNSS backpacks, each equipped with a dual-frequency GNSS receiver and handheld data collector, were used during the survey. Differential corrections were transmitted at 1-Hz intervals by a VHF radio to the backpack GNSS receivers from a GNSS base station placed on a benchmark with known horizontal and vertical coordinates relative to the North American Datum...
thumbnail
In February 2016 the University of Washington in cooperation with the U.S. Geological Survey, Pacific Coastal and Marine Science Center (USGS, PCMSC) collected multibeam bathymetry and acoustic backscatter data in the Catalina Basin aboard the University of Washington's Research Vessel Thomas G. Thompson. Data was collected using a Kongsberg EM300 multibeam echosounder hull-mounted to the 274-foot R/V Thomas G. Thompson. The USGS, PCMSC processed these data and produced a series of bathymetric surfaces and acoustic backscatter images for scientific research purposes. A 25-m bathymetric surface produced from this work was merged with publically available multibeam bathymetry data as well as 2015, 2016, and 2017 multibeam...
thumbnail
This part of the data release includes 10-m resolution merged multibeam-bathymetry data of Catalina Basin and northern Gulf of Santa Catalina. The data are presented as a TIFF file. In February 2016 the University of Washington in cooperation with the U.S. Geological Survey, Pacific Coastal and Marine Science Center (USGS, PCMSC) collected multibeam bathymetry and acoustic backscatter data in Catalina Basin aboard the University of Washington's Research Vessel Thomas G. Thompson. Data were collected using a Kongsberg EM300 multibeam echosounder hull-mounted to the 274-foot R/V Thomas G. Thompson. The USGS, PCMSC processed these data and produced a series of bathymetric surfaces and acoustic backscatter images for...
thumbnail
Vegetation type and density data were collected by the U.S. Geological Survey (USGS) Pacific Coastal and Marine Science Center at three locations in the Sacramento-San Joaquin Delta. Data were collected in Lindsey Slough in April 2017, and Middle River and the Mokelumne River in March 2018. Vegetation samples were collected by divers, and used to determine dry biomass density. These data were collected as part of a cooperative project, with the USGS California Water Science Center and the California Department of Fish and Wildlife, on the effects of invasive aquatic vegetation on sediment transport in the Sacramento-San Joaquin Delta.
thumbnail
This part of the data release presents bathymetry data from the Elwha River delta collected in July 2016 using a kayak. The kayak was equipped with a single-beam echosounder and a survey-grade global navigation satellite system (GNSS) receiver.
thumbnail
Water depth, turbidity, and current velocity time-series data were collected in Liberty Island Conservation Bank (WVA) in 2017. The turbidity sensors were not calibrated to suspended-sediment concentration at this location. Typically, each zip folder for a deployment period contains two data files from a velocimeter and one data file from a CTD, each of which include data from an optical backscatter sensor. --------- Data were collected from several sites in Little Holland Tract (LHT) and Liberty Island (LI), including the Liberty Island Conservation Bank (LICB), from 2015 to 2017. Table 1 (below) lists the deployment name (DLXXX) and dates for each sampling station location. Station names starting with ‘H’ are...
thumbnail
Water depth, turbidity, and current velocity time-series data were collected in Liberty Island from 2015 to 2017. Depth (from pressure) and velocity were measured in high-frequency (8 Hz) bursts. Burst means represent tidal stage and currents, and burst data can be used to determine wave height, period, and direction, and wave-orbital velocity. The turbidity sensors were calibrated to suspended-sediment concentration measured in water samples collected on site. The calibration and fit parameters for all of the turbidity sensors used in the study are tabulated and provided with the data. Data were sequentially added to this data release as they were collected and post-processed. Typically, each zip folder...
thumbnail
This part of the data release provides the U.S. Geological Survey (USGS), Pacific Coastal and Marine Science Center (PCMSC) 2007 bathymetry data collected in Skagit Bay Washington that is provided as a 1-m resolution TIFF image, as well as a 1-m resolution shaded-relief TIFF image. FGDC metadata is also provided. In 2004, 2005, 2007, and 2010 the USGS, PCMSC collected bathymetry and acoustic backscatter data in Skagit Bay, Washington using an interferometric bathymetric sidescan-sonar system mounded to the USGS R/V Parke Snavely and the USGS R/V Karluk. The research was conducted in coordination with the Swinomish Indian Tribal Community, Skagit River System Cooperative, Skagit Watershed Council, Puget Sound Nearshore...
thumbnail
This portion of the USGS data release presents bathymetry data collected during surveys performed on the Elwha River delta, Washington in September 2010 (USGS Field Activity Number W-03-10-PS). Bathymetry data were collected using a small boat and a personal watercraft (PWC), each equipped with single-beam sonar systems and global navigation satellite system (GNSS) receivers. The sonar systems on the survey vessels consisted of an Odom Echotrac CV-100 single-beam echosounder and 200 kHz transducer with a 9° beam angle. Raw acoustic backscatter returns were digitized by the echosounder with a vertical resolution of 1.25 cm. Depths from the echosounders were computed using sound velocity profiles measured using a...
thumbnail
This data release presents beach topography and nearshore bathymetry data from repeated surveys in northern Monterey Bay, California to document changes in shoreline position and coastal morphology as they relate to episodic (storms), seasonal, and interannual and longer (e.g. El Niño) processes. The ongoing monitoring program was initiated in October 2014 with semi-annual surveys performed in late summer (September or October) and Spring (March). Nearshore bathymetry and topography data were collected along a series of shore-perpendicular transects spaced primarily at 50-250 m intervals between Santa Cruz and Moss Landing, California (fig. 1). The transects were located along sandy stretches of the coastline...
thumbnail
This portion of the USGS data release presents topography data collected during surveys performed along northern Monterey Bay, California, in March 2017 (USGS Field Activity Number 2017-620-FA). Topographic profiles were collected on foot with GNSS receivers mounted on backpacks. Prior to data collection, vertical distances between the GNSS antennas and the ground were measured using a tape measure. Hand-held data collectors were used to log raw data and display navigational information allowing surveyors to navigate survey lines spaced at 50- to 250-m intervals along the beach. Profiles were surveyed from the landward edge of the study area (either the base of a bluff, engineering structure, or just landward of...
thumbnail
This portion of the USGS data release presents bathymetry data collected during surveys performed in northern Monterey Bay, California in September 2016 (USGS Field Activity Number 2016-674-FA). Bathymetry data were collected using a personal watercraft (PWC) and small boat equipped with single-beam sonar systems and global navigation satellite system (GNSS) receivers. The sonar systems consisted of an Odom Echotrac CV-100 single-beam echosounder and 200 kHz transducer with a 9° beam angle. Raw acoustic backscatter returns were digitized by the echosounder with a vertical resolution of 1.25 cm. Depths from the echosounders were computed using sound velocity profiles measured using a YSI CastAway CTD during the survey....
thumbnail
This portion of the USGS data release presents bathymetry data collected during surveys performed in northern Monterey Bay, California in March 2016 (USGS Field Activity Number 2016-627-FA). Bathymetry data were collected using two personal watercraft (PWCs) equipped with single-beam sonar systems and global navigation satellite system (GNSS) receivers. The sonar systems consisted of an Odom Echotrac CV-100 single-beam echosounder and 200 kHz transducer with a 9° beam angle. Raw acoustic backscatter returns were digitized by the echosounder with a vertical resolution of 1.25 cm. Depths from the echosounders were computed using sound velocity profiles measured using a YSI CastAway CTD during the survey. Positioning...
thumbnail
This part of the data release presents topography data from northern Monterey Bay, California collected in March 2016 using a tripod-mounted Riegl VZ-1000 lidar scanner (USGS Field Activity 2016-627-FA). For each area surveyed, the scanner was placed at several positions which were selected to provide maximum line-of-sight coverage of the area of interest. Scans were typically conducted in panoramic mode, creating a detailed point cloud of all unobstructed surfaces in a 360 degree view of the scanner. At each scan position, co-registered photographic imagery was also collected with a scanner mounted DSLR camera. Scanner registration was performed by placing four or more cylindrical or flat reflective tripod-mounted...
